Led Traffic Lights – Body and LED Traffic Optics

Specialists in Led Traffic Lights

LED traffic lights for urban roads, pedestrian crossings and traffic lights for trams, complying with international standards and norms.
We lead the traffic lights market.

Led Traffic Light

Traffic light manufacturers and distributors with more than 20 years of experience


Subcategories: Body Traffic LightsOptics Traffic LightsSolar Traffic LightsTraffic Lights TramButtons Traffic Lights


Traffic Light Body

Traffic Light Body 200mm

200 mm system for use in the traffic lights including LED lamps that provide high brightness high visibility.

The disappearance of Ghost Effect caused by the incidence of sun light on the glass is achieved.

Light body can be supplied with an incandescent lamp, LED system or just the single body.

Traffic Lights



Traffic Light Body

FEATURES traffic lights body 100mm, 200mm

Material: Polycarbonate.
Colors: Yellow, Gray, Green, Black and combinations thereof.
Reflector: Anodized aluminum.

  • High Impact resistence.
  • Working temperature from -40 ° C to 74° C.
  • Anti-rotating positioning within intermodulation.
  • Easy lamp replacement and axial adjustment of the light source.
  • Excellent dielectric characteristics. Closing pressure ‘CUC’ with optional coupling screws.
  • Rotationally adjustable visor.



LEDs in our traffic lights

The diode LED is the basic element forming the panels. The type of LED that is used corresponds to a first firm optoelectronics manufacturers.

LED technology is used AlInGaP for red and amber colors and InGaN for the green.

Feeding the diode never exceeds the standard specified in the technical specifications. Supplied by the manufacturers.

The use of LEDs involves a series of advantages over the lamps, such as:

– Lower consumption: Due to the characteristics of LED technology, consumption is reduced by more than 75% over the lamps.

– Increased reliability: The life of the lamps currently used is approximately 20,000 hours of life of the LEDs.

This document contains the technical specification of standard electronic lights for traffic lights.

Cover all the requirements of the European standard (EN 12368).

They have an IP Protection degree IP66 and are guaranteed for 5 years to the end user. Compatibility with electronic traffic controllers is guaranteed.

Technical specification

  • Sizes:
    • 200mm and 300mm.
  • Power supply:
    • 80V versions 250V AC, 50Hz and 12V DC.
  • Safety stabilized and protected from UV radiation.
  • Protection against spikes and transients in the power supply.
  • Built-in fuse.
  • Operating Temperature: -40ºC to +74ºC.
  • With temperature compensation.
  • Protection: IP66.
  • Factor > than 0.9 power.
  • Less than 12W consumption.
    • Red and Amber: 9W to 12W.
    • Green: 10W to 12W.

  • Dominant Wavelength:
    • Red: >-618nm.
    • Amber: 586nm to 596nm.
    • Green: 490nm to 510nm.
  • Number of LEDs lights 200mm:
    • Red: 120.
    • Amber: 120.
    • Green: 120.
  • Number of LEDs lights 300mm:
    • Red: 248.
    • Amber: 248.
    • Green: 128.
  • Loss of brightness due to the failure of a light point: <5%.
  • Warranty: Failure of a point of light: 5 years.

semaphore cases

Led Traffic Light Optics

Red Traffic Light Optic Led

Light unit:
Red 200mm

Outside Diameter: 215mm | (200mm ± 10% according to regulations).
Led Number: 91.


Materials used in the enclosure

Lens: Flat lens transparent polycarbonate with matt external face to avoid glare and reflections. Anti-vandal and extra protection against UV rays.

Board: Solid Polymer EP501.
Housing: ABS.
Gland: Polyamide.
Cable insulation: PVC.

Electrical characteristics

Vn: 230VaC | 42Vac.
In: 40mA | 220mA.
Frequency: 50/60 HZ.
F.P.: >0,9.
Power: 9W.
Reference: 200R220 | 200R42

Optical characteristics

Light intensity distribution: W (wide beam EN12368 / 2008).

Illuminance (reference axis) 379,5 cd.

Ghosting: Class 5.

Color led: 625 nm (wavelength).



According to European standard EN12368/2008

Green Traffic Light Optic Led

Light unit:
Green 200mm

Outside Diameter: 215mm | (200mm ± 10% according to regulations).
Led Number: 91.


Materials used in the enclosure

Lens: Flat lens transparent polycarbonate with matt external face to avoid glare and reflections. Anti-vandal and extra protection against UV rays.

Board: Solid Polymer EP501.
Housing: ABS.
Gland: Polyamide.
Cable insulation: PVC.

Electrical characteristics

Vn: 230VaC | 42Vac.
In: 50mA | 275mA.
Frequency: 50/60 HZ.
F.P.: >0,9.
Power: 11W.
Reference: 200V220SJA | 200V42SJA

Optical characteristics

Light intensity distribution: W (wide beam EN12368 / 2008).

Illuminance (reference axis) 552.3 cd.

Ghosting: Class 5.

Color led: 505 nm (wavelength).



According to European standard EN12368/2008

Amber Traffic Light Optic Led

Light unit:
Amber 200mm

Outside Diameter: 215mm | (200mm ± 10% according to regulations).
Led Number: 91.


Materials used in the enclosure

Lens: Flat lens transparent polycarbonate with matt external face to avoid glare and reflections. Anti-vandal and extra protection against UV rays.

Board: Solid Polymer EP501.
Housing: ABS.
Gland: Polyamide.
Cable insulation: PVC.

Electrical characteristics

Vn: 230VaC | 42Vac.
In: 40mA | 220mA.
Frequency: 50/60 HZ.
F.P.: >0,9.
Power: 9W.
Reference: 200A220SJA | 200A42SJA

Optical characteristics

Light intensity distribution: W (wide beam EN12368 / 2008).

Illuminance (reference axis) 460.5 cd.

Ghosting: Class 5.

Color led: 590 nm (wavelength).



According to European standard EN12368/2008

Pedestrian Optics Traffic Light Led

red pedestrian traffic light

Light unit:
Red pedestrian

Outside Diameter: 215mm | (200mm ± 10% according to regulations).


Materials used in the enclosure

Lens: Flat lens transparent polycarbonate with protection against UV rays. Impact resistance IR3.
Board: Solid Polymer EP501.
Housing: ABS.
Gland: Polyamide.
Cable insulation: PVC.

Electrical characteristics

Vn: 230VaC | 42Vac.
In: 30mA | 150mA.
Frequency: 50/60 HZ.
F.P.: >0,9.
Power: 6W.

Optical characteristics

Light intensity distribution: W (wide beam EN12368/2008).

Illuminance (reference axis): 4000mcd.

Color led: 625nm.



According to European standard EN12368 / 2008

green pedestrian traffic light

Light unit:
Green pedestrian

Outside Diameter: 215mm | (200mm ± 10% according to regulations).


Materials used in the enclosure

Lens: Flat lens transparent polycarbonate with protection against UV rays. Impact resistance IR3.
Board: Solid Polymer EP501.
Housing: ABS.
Gland: Polyamide.
Cable insulation: PVC.

Electrical characteristics

Vn: 230VaC | 42Vac.
In: 30mA | 115mA.
Frequency: 50/60 HZ.
F.P.: >0,9.
Power: 6,5W.

Optical characteristics

Light intensity distribution: W (wide beam EN12368/2008).

Illuminance (reference axis): 4000mcd.

Color led: 505nm (wavelength).



According to European standard EN12368 / 2008



Pictograms Led Traffic Light

200mm optics can include the desired pictogram.

Led Pictograms

Solar traffic lights

Solar traffic lights with LED technology for road and urban lighting. They are ecological ones that use solar lighting for a retroactive charge, obtaining a renewable energy.

More info – Solar traffic lights

Solar traffic light

Traffic Lights Tram

Triangle LED Traffic Light Optic for Tram – ML-ST-TRVTR

More info – Traffic Lights Tram

Traffic Light Tram

Buttons Traffic Lights

More info: Buttons Traffic Lights

Button Crosswalk
